Asme B16.47 Ser,A Class300 Welding Neck Flanges
$35.00 | 1 kg(Min.Order)
ASME B16.47 Class 300 Series A Weld Neck Flanges are a low nitrogen, low-carbon, ferritic steel that offers crevice corrosion resistance and pitting greater to most ferritic alloys.
Features
As a leading manufacturer based in China, we are proud to offer our high-quality product, the Asme B16.47 Ser,A Class300 Welding Neck Flange, to merchants across the world. This durable and versatile item is an essential component for many industrial processes, and we are confident that it will exceed your expectations in terms of performance and value.
Let's start with an overview of the product itself. The Asme B16.47 Ser,A Class300 Welding Neck Flange is designed to be used in high-pressure and high-temperature applications. It is typically used to join pipes, valves, and fittings, and is especially well-suited to applications where there is a need for a secure and leak-proof joint. The welding neck design provides excellent alignment and stability, while the Class300 rating ensures that it can handle high pressure without compromising on safety.
One of the key benefits of our Asme B16.47 Ser,A Class300 Welding Neck Flange is its exceptional durability. Made from high-quality materials, this product is built to withstand extreme temperatures, pressures, and stress. It is also resistant to corrosion, making it ideal for use in harsh environments. Additionally, our product is rigorously tested and certified to meet or exceed industry standards, so you can have peace of mind knowing that it is reliable and safe to use.
In terms of versatility, this product is suitable for use in a wide variety of industries, including oil and gas, petrochemical, chemical, and power generation. Whether you need to transport fluids, gases, or other substances, our Asme B16.47 Ser,A Class300 Welding Neck Flange is an essential component that will ensure a secure and efficient connection.
At our manufacturing facility in China, we use state-of-the-art technology and processes to produce this top-quality product. Our team of engineers and technicians are highly skilled and experienced, and they work tirelessly to ensure that every Asme B16.47 Ser,A Class300 Welding Neck Flange meets our exacting standards for quality and performance.
When you choose our product, you are not just getting a high-quality piece of equipment - you are also gaining access to our exceptional customer service and support. Our team is dedicated to providing you with the assistance you need, whether that's help selecting the right product for your application, technical support, or after-sales service.
We take pride in our ability to provide our customers with a superior product at a competitive price. By choosing our Asme B16.47 Ser,A Class300 Welding Neck Flange, you are investing in a product that will provide long-term value and reliability, and that will help to optimize your operations and improve your bottom line.
In conclusion, if you are looking for a durable, reliable, and versatile flange that can handle high-pressure and high-temperature applications, then look no further than our Asme B16.47 Ser,A Class300 Welding Neck Flange. With its exceptional quality, performance, and value, it is the perfect choice for manufacturers and merchants across the world. Contact us today to learn more about this top-quality product and how it can benefit your operation.
1. Introduction:ASME B16.47 Class 300 Series A Weld Neck Flanges are a low nitrogen, low-carbon, ferritic steel that offers crevice corrosion resistance and pitting greater to most ferritic alloys.
2. Description:ASME B16.47 Class 300 Series A Weld Neck Flange Dimensions has a several exceptional features to offer such as high strength, sturdiness, corrosion resistance, and so on. Impeccably equipped, this Series A Class 300 Weld Neck Flanges is unalloyed in quality and so are considered for soaring temp and all-purpose corrosive service.
| Nominal Pipe Size | Outside Diameter (O) | Minimum Thickness (T) | Raised Face Diameter (R) | Length Thru Hub (Y) | Hub Diameter (X) | Minimum Fillet Radius (r) | Top of Hub (A) | Bore (B) | Approximate Weight (lbs) | Bolt Circle (C) | Number of Holes | Diameter of Holes |
| 26 | 38.25 | 3.12 | 29.5 | 7.25 | 28.38 | 0.38 | 26 | Specified by purchaser | 605 | 34.5 | 28 | 1.75 |
| 28 | 40.75 | 3.38 | 31.5 | 7.75 | 30.5 | 0.44 | 28 | Specified by purchaser | 745 | 37 | 28 | 1.75 |
| 30 | 43 | 3.62 | 33.75 | 8.25 | 32.56 | 0.44 | 30 | Specified by purchaser | 870 | 39.25 | 28 | 1.88 |
| 32 | 45.25 | 3.88 | 36 | 8.75 | 34.69 | 0.44 | 32 | Specified by purchaser | 1005 | 41.5 | 28 | 2 |
| 34 | 47.5 | 4 | 38 | 9.12 | 36.88 | 0.5 | 34 | Specified by purchaser | 1145 | 43.5 | 28 | 2 |
| 36 | 50 | 4.12 | 40.25 | 9.5 | 39 | 0.5 | 36 | Specified by purchaser | 1275 | 46 | 32 | 2.12 |
| 38 | 46 | 4.25 | 40.5 | 7.12 | 39.12 | 0.5 | 38 | Specified by purchaser | 695 | 43 | 32 | 1.62 |
| 40 | 48.75 | 4.5 | 42.75 | 7.62 | 41.25 | 0.5 | 40 | Specified by purchaser | 840 | 45.5 | 32 | 1.75 |
| 42 | 50.75 | 4.69 | 44.75 | 7.88 | 43.25 | 0.5 | 42 | Specified by purchaser | 950 | 47.5 | 32 | 1.75 |
| 44 | 53.25 | 4.88 | 47 | 8.12 | 45.25 | 0.5 | 44 | Specified by purchaser | 1055 | 49.75 | 32 | 1.88 |
| 46 | 55.75 | 5.06 | 49 | 8.5 | 47.38 | 0.5 | 46 | Specified by purchaser | 1235 | 52 | 28 | 2 |
| 48 | 57.75 | 5.25 | 51.25 | 8.81 | 49.38 | 0.5 | 48 | Specified by purchaser | 1380 | 54 | 32 | 2 |
| 50 | 60.25 | 5.5 | 53.5 | 9.12 | 51.38 | 0.5 | 50 | Specified by purchaser | 1530 | 56.25 | 32 | 2.12 |
| 52 | 62.25 | 5.69 | 55.5 | 9.38 | 53.38 | 0.5 | 52 | Specified by purchaser | 1660 | 58.25 | 32 | 2.12 |
| 54 | 65.25 | 6 | 57.75 | 9.94 | 55.5 | 0.5 | 54 | Specified by purchaser | 2050 | 61 | 28 | 2.38 |
| 56 | 67.25 | 6.06 | 59.75 | 10.25 | 57.62 | 0.5 | 56 | Specified by purchaser | 2155 | 63 | 28 | 2.38 |
| 58 | 69.25 | 6.25 | 62 | 10.5 | 59.62 | 0.5 | 58 | Specified by purchaser | 2270 | 65 | 32 | 2.38 |
| 60 | 71.25 | 6.44 | 64 | 10.75 | 61.62 | 0.5 | 60 | Specified by purchaser | 2470 | 67 | 32 | 2.38 |
